1.采用直齒齒輪傳動，經過滲碳淬火處理，齒向齒闊修行處理，表面噴砂鍍鎳，設備運行平穩，噪音小。2.結構簡單，交貨期快，可大批量生產。3.減速機種類齊全...
0510-85167909
產品 · 簡介
TVFR系列性能參數表 / TVFR Series Performance Table | ||||||||
規格 Specification | 單位 Unit | 節數Stage | 減速比Ratio | TVFR60 | TVFR80 | TVFR90 | TVFR120 | TVFR160 |
額定輸出力矩Rated output torqueT2N | Nm | 1 | 3 | 18 | 40 | 50 | 125 | 290 |
4 | 36 | 90 | 110 | 230 | 460 | |||
5 | 40 | 110 | 125 | 260 | 550 | |||
6 | 20 | 40 | 50 | 90 | 340 | |||
7 | 20 | 40 | 50 | 90 | 340 | |||
8 | 12 | 22 | 32 | 70 | 210 | |||
10 | 12 | 22 | 32 | 70 | 210 | |||
2 | 15 | 40 | 110 | 125 | 260 | 550 | ||
20 | 40 | 110 | 125 | 260 | 550 | |||
25 | 40 | 110 | 125 | 260 | 550 | |||
30 | 18 | 40 | 50 | 125 | 290 | |||
35 | 40 | 110 | 125 | 260 | 550 | |||
40 | 36 | 90 | 110 | 230 | 460 | |||
50 | 40 | 110 | 125 | 260 | 550 | |||
60 | 20 | 40 | 50 | 90 | 340 | |||
70 | 20 | 40 | 50 | 90 | 340 | |||
80 | 12 | 22 | 32 | 70 | 210 | |||
100 | 12 | 22 | 32 | 70 | 210 | |||
3 | 64 | 40 | 110 | 125 | 260 | 550 | ||
80 | 40 | 110 | 125 | 260 | 550 | |||
100 | 40 | 110 | 125 | 260 | 550 | |||
150 | 40 | 110 | 125 | 260 | 550 | |||
200 | 40 | 110 | 125 | 260 | 550 | |||
250 | 40 | 110 | 125 | 260 | 550 | |||
350 | 40 | 110 | 125 | 260 | 550 | |||
400 | 40 | 110 | 125 | 260 | 550 | |||
500 | 40 | 110 | 125 | 260 | 550 | |||
700 | 20 | 40 | 50 | 90 | 340 | |||
1000 | 12 | 22 | 32 | 70 | 210 | |||
急停扭矩 / Emergency stop torqueT2NOT | Nm | 1,2,3 | 3 ?1000 | 二倍額定輸出力矩 / Triple rated output torque | ||||
額定輸入轉速 / Rated input speed η1N | rpm | 1,2,3 | 3-1000 | 5000 | 4000 | 4000 | 3000 | 3000 |
******輸入轉速 / Maximum input speed η1B | 1,2,3 | 3-1000 | 10000 | 8000 | 8000 | 6000 | 6000 | |
扭轉剛性 / Torsional rigidity | Nm/arcmin | 1,2,3 | 3-100 | 7 | 14 | 25 | 50 | 145 |
容許徑向力 / Allowable radial force F2aB | N | 1,2,3 | 3-1000 | 1530 | 3250 | 6700 | 9400 | 14500 |
容許軸向力 / Allowable axial force F2aB | N | 1,2,3 | 3-1000 | 765 | 1625 | 3350 | 4700 | 7250 |
使用壽命 / Lifespan | hr | 1,2,3 | 3-1000 | 20000 | ||||
效率 / Efficiency | % | 1 | 3?100 | ≥97% | ||||
2,3 | 15 ~ 1000 | ≥94% | ||||||
重量 / Weight | kg | 1 | 3~10 | 2.1 | 5 | 5 | 8.8 | 30 |
2 | 15 ?100 | 2.7 | 6 | 6 | 10.8 | 34 | ||
3 | 64-1000 | 3.3 | 7 | 7 | 12.8 | 37 | ||
使用溫度 / Working temperature | °C | 1,2,3 | 3-1000 | -10°C~90°C | ||||
潤滑 / Lubricating | 1,2,3 | 合成潤滑油脂 / Synthetic lubricating grease | ||||||
防護等級 / IP Grade | 1,2,3 | 3-1000 | IP65 | |||||
安裝方向 / Installation direction | 1,2,3 | 3-1000 | 任意方向 / In any direction | |||||
噪音值(n1=3000rpm,無負載) Noise level (η1=3000rpm,off load) | dB(A) | 1,2,3 | 3 ?100 | ≤58 | ≤60 | ≤63 | ≤65 | ≤65 |
